Eaton 4A Tag Fuse 22 x 82 mm 0.69kV
- RS Stock No.:
- 228-638
- Mfr. Part No.:
- 4H07-660
- Manufacturer:
- Eaton
Subtotal (1 pack of 20 units)*
PHP58,301.16
(exc. VAT)
PHP65,297.30
(inc. VAT)
FREE delivery for orders over ₱5,000.00
Stocked by manufacturer
- Ready to ship from April 26, 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per Unit* |
|---|---|---|
| 1 + | PHP58,301.16 | PHP2,915.058 |
*price indicative
- RS Stock No.:
- 228-638
- Mfr. Part No.:
- 4H07-660
- Manufacturer:
- Eaton
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Fuse Type | BS | |
| Product Type | Tag Fuse | |
| Fuse Size | 22 x 82 mm | |
| Standards/Approvals | EN 60691:007, EN IEC 6000:018, ANSIESD S0.0:01, RoHS | |
| Application Category | General Industrial Application | |
| Fuse Speed | gL | |
| Fuse Characteristics | gG/gL | |
| Tag Type | Offset Bladed | |
| Overall Length | 84.5mm | |
| Length | 84.5mm | |
| Diameter | 22mm | |
| Height | 22mm | |
| Series | Eaton Bussmann | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Fuse Type BS | ||
Product Type Tag Fuse | ||
Fuse Size 22 x 82 mm | ||
Standards/Approvals EN 60691:007, EN IEC 6000:018, ANSIESD S0.0:01, RoHS | ||
Application Category General Industrial Application | ||
Fuse Speed gL | ||
Fuse Characteristics gG/gL | ||
Tag Type Offset Bladed | ||
Overall Length 84.5mm | ||
Length 84.5mm | ||
Diameter 22mm | ||
Height 22mm | ||
Series Eaton Bussmann | ||
RoHS Status: Exempt
- COO (Country of Origin):
- HU
Eaton Tag Fuse, 4A Current Rating, 22mm Diameter - 4H07-660
This tag fuse provides overcurrent protection for general industrial installations and control equipment, designed to operate at low-voltage distribution levels. It is intended for use where a compact, blade-equipped fuse body is required to isolate circuits safely in machinery and electrical panels.
Features & Benefits
• 4A rated current offering consistent circuit protection and selectivity
• gG/gL characteristic for reliable general-purpose fault interruption
• Rated for 0.69kV enabling use on medium-low voltage systems
• Offset bladed tag for straightforward insertion and removal
• gG/gL characteristic for reliable general-purpose fault interruption
• Rated for 0.69kV enabling use on medium-low voltage systems
• Offset bladed tag for straightforward insertion and removal
**Applications**
• Suitable for industrial control panels requiring replaceable fuses
• Ideal for automation racks protecting motor control circuits
• Used with distribution boards in manufacturing facilities
• Can be used for electrical maintenance in mechanical workshops
• Ideal for automation racks protecting motor control circuits
• Used with distribution boards in manufacturing facilities
• Can be used for electrical maintenance in mechanical workshops
What physical configuration aids installation in confined enclosures?
The component uses an offset blade tag design which permits easier access and handling when space is restricted.
How does the fuse behave under normal load and fault conditions?
It operates with a gG/gL time–current profile, allowing continuous conduction of normal load currents while interrupting overloads and short-circuit faults.
What are the overall size considerations for panel layout planning?
The assembly has a nominal cross-section diameter of 22mm and an overall length of 84.5mm, which should be allocated when planning fuse holder spacing.
