    Honeywell LS Series Plunger Limit Switch, IP67, SPDT, Die Cast Zinc Housing, 480V ac Max, 10A Max

    Honeywell
    RS Stock No.:
    311-2134
    Mfr. Part No.:
    5LS1-4CN152
    Manufacturer:
    Honeywell
    View all Limit Switches
    25 In Global stock for delivery NCR Plus within 10 working day(s), rest of PH within 14 working days
    Add to Basket
    units

    Added

    Price Each

    PHP17,637.11

    (exc. VAT)

    PHP19,753.56

    (inc. VAT)

    unitsPer Unit
    1 +PHP17,637.11
    RS Stock No.:
    311-2134
    Mfr. Part No.:
    5LS1-4CN152
    Manufacturer:
    Honeywell

    Legislation and Compliance

    COO (Country of Origin):
    GB

    Product Details

    Oil Resistant, High Temperature Limit Switches


    2 Circuit, Double Break Snap Action Basic Switch
    Positive break NC contact
    O-ring seals on actuator shaft
    Ring seal between head and body
    Seated compression seal between cover and case
    Compact, rugged construction, sealed to IP67
    Operating temperature range of -10 to +150°C
    NEMA 1, 4 & 13

    Standards

    EN60947-5-1, IEC947-5-1

    Honeywell Limit Switch, Top Roller Plunger Actuator, 31.4N Operating Force - LS Series - 5LS1-4CN152


    Use this limit switch from Honeywell to sense the presence of objects in your machinery. It has an IP67 rating, so it's dust-tight and can withstand submersion in 1m of water for up to 30 minutes. Thanks to its die-cast zinc construction, it's resistant to corrosion and impact for use in harsh environments.

    Features & Benefits


    • Current rating of 10A for use in high-power applications
    • Roller plunger actuator is made of steel for resistance to corrosion and wear
    • SPDT circuitry means it can control up to two devices at once for versatility

    Applications


    • Material handling
    • Power plants
    • Assembly lines
    • Door interlock systems

    How do I install this limit switch?


    This limit switch has pre-drilled mounting holes, so you can securely screw it in place on your equipment.

    Approvals

    UL; CSA

    Specifications

    Attribute
    Value
    Actuator TypePlunger
    Pole and Throw ConfigurationSPDT
    IP RatingIP67
    Maximum Current10A
    Housing MaterialDie Cast Zinc
    Maximum AC Voltage480V
    Maximum DC Voltage550V
    SeriesLS
    Action TypeSnap Action
    Length98.6mm
    Maximum Operating Temperature+150°C
    Width40mm
    Minimum Operating Temperature-10°C
    Standards MetCSA
    Depth58.5mm
    Operating Force31.4 N
