SKF W 61901-2Z 1 Row Ball Bearing - 12 mm ID, 24 mm OD
- RS Stock No.:
- 208-0468
- Mfr. Part No.:
- W 61901-2Z
- Manufacturer:
- SKF
Subtotal (1 unit)*
PHP2,336.91
(exc. VAT)
PHP2,617.34
(inc. VAT)
FREE delivery for orders over ₱3,000.00
In Stock
- Plus 61 unit(s) shipping from April 27, 2026
- Plus 267 unit(s) shipping from May 21, 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 + | PHP2,336.91 |
*price indicative
- RS Stock No.:
- 208-0468
- Mfr. Part No.:
- W 61901-2Z
- Manufacturer:
- SKF
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Ball Bearing | |
| Inside Diameter | 12mm | |
| Outside Diameter | 24mm | |
| Race Width | 6mm | |
| Cage Material | Sheet Metal | |
| Ball Material | Stainless Steel | |
| End Type | Shielded | |
| Number of Rows | 1 | |
| Static Load Rating | 1.46kN | |
| Internal Clearance | CN | |
| Dynamic Load Rating | 2.51kN | |
| Bore Type | Parallel | |
| Standards/Approvals | No | |
| Series | 1 Extra Light Thrust | |
| Limiting Speed | 32000rpm | |
| Bearing Type | Single Row Deep Groove Ball | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Ball Bearing | ||
Inside Diameter 12mm | ||
Outside Diameter 24mm | ||
Race Width 6mm | ||
Cage Material Sheet Metal | ||
Ball Material Stainless Steel | ||
End Type Shielded | ||
Number of Rows 1 | ||
Static Load Rating 1.46kN | ||
Internal Clearance CN | ||
Dynamic Load Rating 2.51kN | ||
Bore Type Parallel | ||
Standards/Approvals No | ||
Series 1 Extra Light Thrust | ||
Limiting Speed 32000rpm | ||
Bearing Type Single Row Deep Groove Ball | ||
SKF 1 Extra Light Thrust Series Ball Bearing, 2.51 kN Dynamic Load Rating, 24mm Outside Diameter - W 61901-2Z
This ball bearing belongs to the deep groove category and is intended for high-performance applications. With an inside diameter of 12mm and an outside diameter of 24mm, it features a single-row design. The bearing is shielded on both sides to protect against contaminants while maintaining smooth operation. Constructed from stainless steel, it offers durability suitable for various industrial uses.
Features & Benefits
• Single-row design supports effective rotational movement
• Shielded construction protects against dust and debris
• Stainless steel material enhances corrosion resistance
• High dynamic load rating ensures solid performance
• Low friction from design promotes longevity
Applications
• Utilised in automotive settings for axle and wheel assemblies
• Suitable for electric motors requiring dependable rotation
• Ideal for machinery in the automation field
• Commonly used in equipment requiring robust bearing solutions
• Found in consumer appliances where durability is important
Can it withstand high-speed operations?
Yes, it has a limiting speed of 32000r/min.
Can it support heavy loads?
Yes, it features a high static load rating of 1.46kN.
Is it easy to install?
Yes, it is designed for straightforward installation across various applications.
