Festo 1/4 in R Threaded Pressure Gauge, 50 mm, 16 bar

View all Pressure Gauges

Subtotal (1 unit)*

PHP2,221.00

(exc. VAT)

PHP2,487.52

(inc. VAT)

Add to Basket
Select or type quantity
Stocked by manufacturer
  • Ready to ship from June 29, 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per Unit
1 +PHP2,221.00

*price indicative

RS Stock No.:
203-1544
Mfr. Part No.:
MA-50-1,6-R1/4-MPA-E-RG
Manufacturer:
Festo
Find similar products by selecting one or more attributes.
Select all

Brand

Festo

Product Type

Pressure Gauge

Maximum Pressure Measurement

16bar

Minimum Pressure Measurement

0bar

Pressure Connection

Brass

Connection Size

1/4 in R

Connection Type

Threaded

Series

MA

Case Material

ABS

Dial Colour

Black

Connection Location

Back Entry

Dial Size

50mm

Maximum Operating Temperature

60°C

Standards/Approvals

RoHS

COO (Country of Origin):
PL
The Festo pressure gauge MA-50-1,6-R1/4-MPA-E-RG With display unit in MPa, adjustable red/green range. It has operating temperature ranges between –20°C and 60°C.

Indicating range [MPa] 0 - 1,6 Mpa

Conforms to standard EN 837-1

Nominal size of pressure gauge 50

Design structure Bourdon-tube pressure gauge

Mounting type Line installation
