Texas Instruments, Transceiver IC 1 LVTTL Receiver, Driver, 8-Pin SOIC

This image is representative of the product range

View all LVDS Interface Ics
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
RS Stock No.:
121-8570
Mfr. Part No.:
SN65LVDS179D
Manufacturer:
Texas Instruments
Find similar products by selecting one or more attributes.
Select all

Brand

Texas Instruments

Product Type

Transceiver IC

Number of Drivers

1

Input Type

LVTTL

Number of Receivers

1

Output Type

Receiver, Driver

Sub Type

Transceiver

Transmission Data Rate

400Mbps

Number of Elements per Chip

1

Mount Type

Surface

Package Type

SOIC

Pin Count

8

Differential Input High Threshold Voltage

100mV

Minimum Supply Voltage

3V

Maximum Supply Voltage

3.6V

Differential Input Low Threshold Voltage

-100mV

ESD Protection

Yes

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

85°C

Width

3.91 mm

Height

1.58mm

Standards/Approvals

RoHS

Length

4.9mm

Series

SN65LVDS179

Automotive Standard

No

LVDS Transceivers, Texas Instruments


LVDS Communication


Low Voltage Differential Signaling, or LVDS, is an electrical signaling system that can run at very high speeds over cheap, twisted-pair copper cables.

Applications: Firewire, SATA, SCSI
