Festo P Stainless Steel Filter Regulator, 5μm, G 1/4, Manual, 20 bar, 4787803

RS Stock No.:: 288-2870
Mfr. Part No.:: PCRP-64-G14-7-C-R1-M-T18
Manufacturer:: Festo

Festo P Stainless Steel Filter Regulator, 5μm, G 1/4, Manual, 20 bar, 4787803

Subtotal (1 unit)*

PHP23,579.56

(exc. VAT)

PHP26,409.11

(inc. VAT)

FREE delivery for orders over ₱3,000.00

Temporarily out of stock

Shipping from January 05, 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per Unit
1 +	PHP23,579.56

*price indicative

RS Stock No.:: 288-2870
Mfr. Part No.:: PCRP-64-G14-7-C-R1-M-T18
Manufacturer:: Festo

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Festo
	Port Connection	G 1/4
	Maximum Operating Pressure	20 bar
	Manufacturer Series	P
	Drain Type	Manual
	Filtration Size	5µm
	Pressure Gauge Port	G 1/4
	Pressure Gauge Port Thread Size	1/4 in
	Port Connection Thread Size	1/4 in
	Maximum Ambient Operating Temperature	+80°C
	Minimum Process Operating Temperature	-20°C
	Minimum Operating Pressure	1bar
	Maximum Process Operating Temperature	+80°C
	Port Connection Thread Standard	G
	Pressure Gauge Port Thread Standard	G
	Ambient Operating Temperature Range	-20 → +80°C
	Minimum Ambient Operating Temperature	-20°C
	Process Operating Temperature Range	-20 → +80°C
	Bowl Material	Stainless Steel
	Model Number	4787803

	Select all
	Brand Festo
	Port Connection G 1/4
	Maximum Operating Pressure 20 bar
	Manufacturer Series P
	Drain Type Manual
	Filtration Size 5µm
	Pressure Gauge Port G 1/4
	Pressure Gauge Port Thread Size 1/4 in
	Port Connection Thread Size 1/4 in
	Maximum Ambient Operating Temperature +80°C
	Minimum Process Operating Temperature -20°C
	Minimum Operating Pressure 1bar
	Maximum Process Operating Temperature +80°C
	Port Connection Thread Standard G
	Pressure Gauge Port Thread Standard G
	Ambient Operating Temperature Range -20 → +80°C
	Minimum Ambient Operating Temperature -20°C
	Process Operating Temperature Range -20 → +80°C
	Bowl Material Stainless Steel
	Model Number 4787803

COO (Country of Origin):: IN

Festo Series P Filter Regulator, 1/4in Port Connection, 20 bar Maximum Operating Pressure - PCRP-64-G14-7-C-R1-M-T18, Numeric Part Number: 4787803

This filter regulator is designed for efficient control of compressed air and inert gases. It features a robust stainless steel construction and operates effectively within a temperature range of -20°C to +80°C. The manual drain function allows for easy maintenance, making it suitable for various industrial applications.

Features & Benefits

• Adjustable pressure regulation range from 0.5 bar to 7 bar
• Manual drain feature simplifies condensate removal
• Designed for vertical mounting, ensuring versatility in installation
• Prepared for G1/4 pressure gauge port for monitoring pressure levels
• Conforms to NACE MR0175/ISO 15156 for enhanced durability

Applications

• Used with pneumatic systems for air supply regulation
• Ideal for requiring high pressure management
• Compatible for use in industrial automation processes
• Suitable for environments demanding high air purity standards

How is the filtration size relevant for operation?

The 5 μm filtration size effectively removes contaminants, improving system efficiency and prolonging equipment life.

What temperature range can be accommodated during operation?

This device can operate efficiently in ambient temperatures from -20°C to +80°C, ensuring reliable performance across various conditions.

How is pressure regulation achieved with this product?

Utilising primary pressure compensation, it maintains stable output pressure while handling fluctuations in input pressure.

What materials are used in the construction of this filter regulator?

It features a stainless steel housing and bowl, with components made from high-alloy stainless steel for corrosion resistance and durability in demanding environments.
