Schneider Electric ClimaSys Series Filter Fan, 230 V ac, AC, 54 m³/h Filtered, 170 m³/h Unimpeded, IP33, 120 mm, 120 mm
- RS Stock No.:
- 689-9809
- Distrelec Article No.:
- 304-01-299
- Mfr. Part No.:
- NSYCVF54M230MM2
- Manufacturer:
- Schneider Electric
Bulk discount available
Subtotal (1 unit)*
PHP5,486.68
(exc. VAT)
PHP6,145.08
(inc. VAT)
FREE delivery for orders over ₱3,000.00
In Stock
- Plus 40 unit(s) shipping from March 30, 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 - 4 | PHP5,486.68 |
| 5 + | PHP4,515.55 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 689-9809
- Distrelec Article No.:
- 304-01-299
- Mfr. Part No.:
- NSYCVF54M230MM2
- Manufacturer:
- Schneider Electric
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Product Type | Filter Fan | |
| Unimpeded Air Flow | 170m³/h | |
| Filtered Air Flow | 54m³/h | |
| AC or DC Operation | AC | |
| Installation Depth | 38mm | |
| Face Height | 120mm | |
| Face Width | 120mm | |
| Standards/Approvals | RoHS | |
| Better World Product | Yes | |
| IP Rating | IP33 | |
| Series | ClimaSys | |
| Configuration | Square | |
| Special Features | Anti-insect | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Product Type Filter Fan | ||
Unimpeded Air Flow 170m³/h | ||
Filtered Air Flow 54m³/h | ||
AC or DC Operation AC | ||
Installation Depth 38mm | ||
Face Height 120mm | ||
Face Width 120mm | ||
Standards/Approvals RoHS | ||
Better World Product Yes | ||
IP Rating IP33 | ||
Series ClimaSys | ||
Configuration Square | ||
Special Features Anti-insect | ||
- COO (Country of Origin):
- CN
Schneider Electric Filter Fan, Steel Grille, 96 (H) x 96mm (W) Cutout Dimensions - ClimaSys Series - NSYCVF54M230MM2
Keep your industrial enclosure cool with this filter fan from Schneider Electric. It's a compact but efficient ventilation solution to help regulate the temperature inside a busy control cabinet. The powerful axial motor delivers a solid 170m³/h unimpeded airflow to dissipate hot-air build-up before it causes damage to sensitive components. As the filter itself is manufactured from durable stainless steel, you can count on this hardy piece of kit to hold its own in demanding environments.
Features & Benefits
• Supplied complete with 2 insect filters to restrict bugs and other contaminants from getting in
• 230V input voltage is compatible with mains supplies for hassle-free installation
• Compact dimensions of 96 (H) x 96mm (W) fit comfortably on standard enclosures
Applications
• Automotive workshops
• Data centres
• Public conveniences
• Server rooms
Is this filter fan IP-rated?
Yes, it comes with an IP33 rating. This means it's protected against solid objects over 2.5mm, such as small tools and wires. It also resists moisture sprayed directly at angles up to 60° off the vertical for uninterrupted air circulation.
IP33 ventilation kit
Ventilation kit comprising: - 1 ventilator 120 x 120 38 mm, 230 V - 50 / 60 Hz, free flow rate of 170 m³/h, IP33 / IK10,- 2 metal eyelets 120 x 120 mm, grey RAL 7032, - 2 anti-insect grills 115 x 98 mm, stainless steel wire, Ø 0.32 mm braided, 1.07 mm mesh, - 1 power cord, - screws. Assembly flow rate: 54 m³/h. Protection index IP33 and IK10.
