RS PRO Yellow Die Cast Aluminium Push Button Enclosure - 1 Hole 22.5 mm Diameter
- RS Stock No.:
- 136-8582
- Manufacturer:
- RS PRO
Subtotal (1 unit)*
PHP1,922.57
(exc. VAT)
PHP2,153.28
(inc. VAT)
FREE delivery for orders over ₱3,000.00
In Stock
- 150 unit(s) ready to ship from another location
- Plus 42 unit(s) shipping from October 28, 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 + | PHP1,922.57 |
*price indicative
- RS Stock No.:
- 136-8582
- Manufacturer:
- RS PRO
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Product Type | Push Button Enclosure | |
| Cutout Diameter | 22.5mm | |
| Number of Cutouts | 1 | |
| Enclosure Colour | Yellow | |
| Enclosure Material | Die Cast Aluminium | |
| IP Rating | IP65 | |
| Length | 105mm | |
| Width | 68mm | |
| Depth | 51mm | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | RoHS | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Product Type Push Button Enclosure | ||
Cutout Diameter 22.5mm | ||
Number of Cutouts 1 | ||
Enclosure Colour Yellow | ||
Enclosure Material Die Cast Aluminium | ||
IP Rating IP65 | ||
Length 105mm | ||
Width 68mm | ||
Depth 51mm | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals RoHS | ||
- COO (Country of Origin):
- IN
RS PRO Aluminium Push Button Enclosure
Stay in control with this RS PRO aluminium push-button enclosure. A robust and dependable housing, designed to accommodate 22.5 mm push-buttons and selector switches in industrial settings.
Made from diecast aluminium, this control station enclosure offers strength, durability, and corrosion resistance while withstanding harsh conditions.
Upon inspection, the enclosure features a grey body with an intense yellow front, maximising visibility and enhancing safety in busy industrial environments. With its durability and IP65 rating, this unit thrives in environments with wide temperature variations, safeguarded against dust and low-pressure water jets.
Features and Benefits
Dimensions
Applications
Enclosures featured come with 22mm holes unless otherwise stated.
