MPN

RS PRO, 10 Ω 100 W Wirewound Chassis Mount Resistor ±5 %

RS Stock No.:: 185-2422
Manufacturer:: RS PRO

RS PRO, 10 Ω 100 W Wirewound Chassis Mount Resistor ±5 %

Get a bulk buy discount

Add 5 more to save 3%

View bulk pricing options

Subtotal (1 unit)*

PHP937.18

(exc. VAT)

PHP1,049.64

(inc. VAT)

FREE delivery for orders over ₱5,000.00

In Stock

38 unit(s) ready to ship from another location
Plus 230 unit(s) shipping from December 02, 2026
Plus 50 unit(s) shipping from April 21, 2027

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per Unit	Saving
1 - 4	PHP937.18	-
5 - 9	PHP899.70	3%
10 - 19	PHP862.22	7%
20 +	PHP843.46	10%

*price indicative

RS Stock No.:: 185-2422
Manufacturer:: RS PRO

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Product Type	Chassis Mount Resistor
	Resistance	10Ω
	Power Rating	100W
	Series	RS PRO
	Package/Case	Aluminium
	Tolerance	±5 %
	Technology	Wirewound
	Automotive Standard	No
	Termination Style	Wire Lead
	Overall Length	100mm
	Minimum Operating Temperature	-25°C
	Maximum Operating Temperature	250°C
	Overall Width	75mm
	Standards/Approvals	UL1330
	Overall Height	5.7mm

	Select all
	Brand RS PRO
	Product Type Chassis Mount Resistor
	Resistance 10Ω
	Power Rating 100W
	Series RS PRO
	Package/Case Aluminium
	Tolerance ±5 %
	Technology Wirewound
	Automotive Standard No
	Termination Style Wire Lead
	Overall Length 100mm
	Minimum Operating Temperature -25°C
	Maximum Operating Temperature 250°C
	Overall Width 75mm
	Standards/Approvals UL1330
	Overall Height 5.7mm

COO (Country of Origin):: IN

RS PRO Panel Mount Resistor

The RS PRO RSLPR100 series aluminium housed panel mount resistor has a resistance of 10ohm and power rating value of 100W. Its dimensions are 100mm x 75mm x 5.7mm (L x W x H). This low profile resistor is suitable for multiple industries and applications.

Features and Benefits

• Operating temperature ranging between -25°C and 250°C

• Tolerance: ±5%

• Dielectric strength: 2500VAC-rms for 1 minute

• Minimum insulation resistance: 100Mohm

Applications

• Electrical vehicles

• Power supplies

• Control devices

• Robotics

Certifications

• ANSI/ESD S20.20:2014

• BS EN 61340-5-1:2007
