Name: Renesas Electronics, Bus Switch, 2 x 4:1, 14-Pin SOIC
Brand: Renesas Electronics
SKU: 263-8027
Price: 24.50 PHP
Availability: Discontinued

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Renesas Electronics
	Product Type	Bus Switch
	Logic Family	CMOS/TTL
	Configuration	2 x 4:1
	Number of Elements per Chip	20
	Maximum Quiescent Current	3μA
	Minimum Supply Voltage	3.3V
	Package Type	SOIC
	Maximum Supply Voltage	5V
	Pin Count	14
	Maximum High Level Output Current	1.5mA
	Minimum Operating Temperature	-40°C
	Maximum Propagation Delay Time @ CL	0.25ns
	Maximum On State Resistance	15Ω
	Maximum Operating Temperature	85°C
	Standards/Approvals	No
	Series	IDTQS3253
	Automotive Standard	No

	Select all
	Brand Renesas Electronics
	Product Type Bus Switch
	Logic Family CMOS/TTL
	Configuration 2 x 4:1
	Number of Elements per Chip 20
	Maximum Quiescent Current 3μA
	Minimum Supply Voltage 3.3V
	Package Type SOIC
	Maximum Supply Voltage 5V
	Pin Count 14
	Maximum High Level Output Current 1.5mA
	Minimum Operating Temperature -40°C
	Maximum Propagation Delay Time @ CL 0.25ns
	Maximum On State Resistance 15Ω
	Maximum Operating Temperature 85°C
	Standards/Approvals No
	Series IDTQS3253
	Automotive Standard No

Datasheet - QS3253S1G8

The Renesas Electronics a high-speed CMOS TTL-compatible 8:1 multiplexer/demultiplexer. It has 3-state outputs. The low ON resistance of the QS3251 allows inputs to be connected to outputs without adding propagation delay and without generating additional ground bounce noise.

Enhanced N channel FET with no inherent diode to Vcc

5Ω bidirectional switches connect inputs to outputs

Undershoot clamp diodes on all switch and control inputs

TTL-compatible control inputs

Renesas Electronics, Bus Switch, 2 x 4:1, 14-Pin SOIC
