SKF 6215-2RS1 Single Row Deep Groove Ball Bearing- Both Sides Sealed 75mm I.D, 130mm O.D

Sealed (2RS1) bearings are fitted with two synthetic rubber seals to prevent leakage of lubricant and entry of dust, water and other harmful material.

• The seals are made from an oil and wear-resistant synthetic rubber with a steel reinforcement
• Operating temperature from -40°C to +120°C
• Accepts radial and axial loads
• Both standard and C3 clearance available
• Versatile

Deep groove ball bearings are suitable for high speeds and are robust in operation.

This deep groove ball bearing, designed for high-performance applications, features a robust construction ideal for varied mechanical needs. With an inside diameter of 75mm and an outside diameter of 130mm, it incorporates a single-row design and sealing arrangements on both sides to ensure durability and reliability. This product is particularly suited for environments where dirt and moisture are concerns, enhancing longevity and performance.

• Sealing on both sides protects against contamination
• Designed for a high dynamic load rating of 68.9kN
• Steel construction promotes strength and wear resistance
• Cylindrical bore facilitates easy installation
• Single-row design ensures smooth operation and efficiency
• Suitable for high-speed applications of up to 3200 r/min

• Used for electric motors for reliable rotation
• Ideal for enhanced mechanical performance
• Suitable for conveyor systems requiring smooth movement
• Recommended for pumps where sealing and precision are critical

A dynamic load rating of 68.9kN indicates the bearing's ability to withstand substantial loads during operation without risking premature failure, making it suitable for high-stress applications.

The dual sealing arrangement prevents the ingress of contaminants, significantly extending the bearing's operational life in environments where dust and moisture are prevalent.

The cylindrical bore design allows for straightforward and precise fitting onto various shafts, ensuring proper alignment and efficient function in diverse applications.
