RS PRO BSP 1/8 in BSP 1/8 in Pressure Gauge, 40 mm, 30 psi

RS Stock No.:: 235-1289
Manufacturer:: RS PRO

RS PRO BSP 1/8 in BSP 1/8 in Pressure Gauge, 40 mm, 30 psi

Subtotal (1 unit)*

PHP804.90

(exc. VAT)

PHP901.49

(inc. VAT)

FREE delivery for orders over ₱3,000.00

In Stock

6 unit(s) ready to ship from another location
Plus 100 unit(s) shipping from April 02, 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per Unit
1 +	PHP804.90

*price indicative

RS Stock No.:: 235-1289
Manufacturer:: RS PRO

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Product Type	Pressure Gauge
	Maximum Pressure Measurement	30psi
	Minimum Pressure Measurement	0psi
	Pressure Connection	Brass
	Connection Size	BSP 1/8 in
	Connection Type	BSP 1/8 in
	Case Material	Steel
	Connection Location	Rear
	Dial Size	40 mm
	Maximum Operating Temperature	60°C
	Standards/Approvals	No

	Select all
	Brand RS PRO
	Product Type Pressure Gauge
	Maximum Pressure Measurement 30psi
	Minimum Pressure Measurement 0psi
	Pressure Connection Brass
	Connection Size BSP 1/8 in
	Connection Type BSP 1/8 in
	Case Material Steel
	Connection Location Rear
	Dial Size 40 mm
	Maximum Operating Temperature 60°C
	Standards/Approvals No

Manufacturer Information

RoHS Status: Exempt

COO (Country of Origin):: TW

RS PRO Back Entry Pressure Gauge 30psi, 0psi min.

This RS PRO tried and tested dual scale pressure gauge with centre back connection can be used across a wide range of equipment. The pressure gauge has a steel case which makes it strong and durable in many environments.

This RS PRO pressure gauge has been designed with the highest quality and versatility in mind and features 1/8” BSPT thread with 0 to 2 bar pressure and a 40 mm gauge diameter.

Features and Benefits

Dual scale bar/psi gauge with bottom connection

Stainless steel case, aluminium dial and a pointer

1/8 inch BSPT with 0 to 2 bar pressure and a 40 mm gauge diameter

±3-2-3% ANSI/ASME Grade B

Applications

Air conditioning systems;Heating systems;Compressors;Medical engineering;Operating machinery;Hydraulics systems
