SMC R 1/8 Analogue Pressure Gauge 7bar Back Entry 42mm Outside Diameter
- RS Stock No.:
- 232-9023
- Mfr. Part No.:
- G46-7-01-C
- Manufacturer:
- SMC
Subtotal (1 unit)*
PHP1,208.02
(exc. VAT)
PHP1,352.98
(inc. VAT)
FREE delivery for orders over ₱3,000.00
In Stock
- 5 unit(s) ready to ship from another location
- Plus 23 unit(s) shipping from March 11, 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 + | PHP1,208.02 |
*price indicative
- RS Stock No.:
- 232-9023
- Mfr. Part No.:
- G46-7-01-C
- Manufacturer:
- SMC
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Maximum Pressure Measurement | 7bar | |
| Mounting Type | Back Entry | |
| Minimum Pressure Measurement | 0bar | |
| Display Type | Analogue | |
| Connection Size | R 1/8 | |
| Gauge Outside Diameter | 42mm | |
| Select all | ||
|---|---|---|
Brand SMC | ||
Maximum Pressure Measurement 7bar | ||
Mounting Type Back Entry | ||
Minimum Pressure Measurement 0bar | ||
Display Type Analogue | ||
Connection Size R 1/8 | ||
Gauge Outside Diameter 42mm | ||
- COO (Country of Origin):
- JP
The SMC G46 series pressure gauges including general purpose, oil-free/external parts copper-free with limit indicator, clean series and a pressure gauge with a pressure switch. It has pressure ranges vary from 0 to 1.5MPa, depending on the selected gauge. It used panel mounting is possible.
General purpose gauge w/limit indicator
Back or vertical side thread
Indication precision ±3% F.S. (full span)
