WIKA G 1/8 Threaded Pressure Gauge, 40 mm, 6 bar

RS Stock No.:: 219-0780
Mfr. Part No.:: 9083715
Manufacturer:: WIKA

WIKA G 1/8 Threaded Pressure Gauge, 40 mm, 6 bar

Subtotal (1 unit)*

PHP747.52

(exc. VAT)

PHP837.22

(inc. VAT)

Stock information currently inaccessible - Please check back later

Units	Per Unit
1 +	PHP747.52

*price indicative

RS Stock No.:: 219-0780
Mfr. Part No.:: 9083715
Manufacturer:: WIKA

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	WIKA
	Maximum Pressure Measurement	6bar
	Product Type	Pressure Gauge
	Minimum Pressure Measurement	0bar
	Pressure Connection	Copper
	Connection Size	G 1/8
	Connection Type	Threaded
	Series	111.XX
	Case Material	Plastic
	Dial Colour	Black
	Dial Size	40mm
	Connection Location	Back Entry
	Maximum Operating Temperature	60°C
	Standards/Approvals	CE, PAC, UL

	Select all
	Brand WIKA
	Maximum Pressure Measurement 6bar
	Product Type Pressure Gauge
	Minimum Pressure Measurement 0bar
	Pressure Connection Copper
	Connection Size G 1/8
	Connection Type Threaded
	Series 111.XX
	Case Material Plastic
	Dial Colour Black
	Dial Size 40mm
	Connection Location Back Entry
	Maximum Operating Temperature 60°C
	Standards/Approvals CE, PAC, UL

Datasheet - 9083715

RoHS Status: Exempt

The WIKA bourdon tube pressure gauge is based on the proven bourdon tube measuring system. On pressurisation, the deflection of the Bourdon tube, proportional to the incident pressure, is transmitted to the movement via a link and indicated. The modular design enables a multitude of combinations of case materials, process connections, nominal sizes and scale ranges. Due to this high variance, the instrument is suitable for use in a wide range of applications within industry.

It is reliable and cost-effective

Designed as per EN 837-1

It can be used for gaseous and liquid media that are not highly viscous or crystallising and will not attack copper alloy parts
