Bourdon G 1/4 Bottom Pressure Gauge, 63 mm, 4 bar

Name: Bourdon G 1/4 Bottom Pressure Gauge, 63 mm, 4 bar
Brand: Bourdon
SKU: 184-6074
Price: 7543.04 PHP
Availability: InStock

Bulk discount available

Subtotal (1 unit)*

PHP6,734.86

(exc. VAT)

PHP7,543.04

(inc. VAT)

Stock information currently inaccessible - Please check back later

Units	Per Unit
1 - 9	PHP6,734.86
10 +	PHP6,600.16

*price indicative

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Bourdon
	Product Type	Pressure Gauge
	Maximum Pressure Measurement	4bar
	Minimum Pressure Measurement	0bar
	Pressure Connection	G 1/4
	Connection Size	G 1/4
	Accuracy	±1.6 %
	Connection Type	Bottom
	Series	MEX3
	Case Material	Stainless Steel
	Dial Colour	White
	Dial Size	63mm
	Connection Location	Bottom Entry
	Maximum Operating Temperature	70°C
	Standards/Approvals	Lloyds Register Approval, EN 837-1, ATEX Ex II 2 GDc-IM2c

	Select all
	Brand Bourdon
	Product Type Pressure Gauge
	Maximum Pressure Measurement 4bar
	Minimum Pressure Measurement 0bar
	Pressure Connection G 1/4
	Connection Size G 1/4
	Accuracy ±1.6 %
	Connection Type Bottom
	Series MEX3
	Case Material Stainless Steel
	Dial Colour White
	Dial Size 63mm
	Connection Location Bottom Entry
	Maximum Operating Temperature 70°C
	Standards/Approvals Lloyds Register Approval, EN 837-1, ATEX Ex II 2 GDc-IM2c

RoHS Status: Exempt

MEX Industrial pressure gauge, Nominal size 63 mm

For corrosive gasses and liquids

Class 1.6 according to EN 837-1

Wetted parts: Stainless steel

Case with crimped bezel ring

Lloyds Register Approval

Option: Liquid-filled for applications with pulsations or vibrations

Option: Case material 1.4404 (316L) for aggressive atmosphere
