Global Laser 1260-39-000 Laser Module 850 nm 2.8 mW Diode, TTL control Ellipse pattern 5 V 3.3 V
- RS Stock No.:
- 210-7342
- Mfr. Part No.:
- 1260-39-000
- Manufacturer:
- Global Laser
Bulk discount available
Subtotal (1 unit)*
PHP11,884.30
(exc. VAT)
PHP13,310.42
(inc. VAT)
FREE delivery for orders over ₱3,000.00
Temporarily out of stock
- Shipping from March 24, 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 - 49 | PHP11,884.30 |
| 50 - 249 | PHP11,052.41 |
| 250 + | PHP9,947.17 |
*price indicative
- RS Stock No.:
- 210-7342
- Mfr. Part No.:
- 1260-39-000
- Manufacturer:
- Global Laser
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Global Laser | |
| Product Type | Laser Module | |
| Laser Type | Diode | |
| Emission Pattern | Ellipse | |
| Laser Wavelength | 850nm | |
| Optical Output Power | 2.8mW | |
| Control Type | TTL | |
| Laser Class | 3R | |
| Minimum Operating Temperature | -10°C | |
| Maximum Operating Temperature | 45°C | |
| Length | 24mm | |
| Maximum Supply Voltage | 5V | |
| Standards/Approvals | No | |
| Series | 1206 | |
| Supply Current | 30mA | |
| Automotive Standard | No | |
| Minimum Supply Voltage | 3.3V | |
| Select all | ||
|---|---|---|
Brand Global Laser | ||
Product Type Laser Module | ||
Laser Type Diode | ||
Emission Pattern Ellipse | ||
Laser Wavelength 850nm | ||
Optical Output Power 2.8mW | ||
Control Type TTL | ||
Laser Class 3R | ||
Minimum Operating Temperature -10°C | ||
Maximum Operating Temperature 45°C | ||
Length 24mm | ||
Maximum Supply Voltage 5V | ||
Standards/Approvals No | ||
Series 1206 | ||
Supply Current 30mA | ||
Automotive Standard No | ||
Minimum Supply Voltage 3.3V | ||
- COO (Country of Origin):
- GB
The Global Laser 30mA Gated Cameo is a miniature laser diode module that has a threaded barrel for easy bulkhead mounting which ensures good thermal contact between module and heat sink. It offers high output power stability with transient and polarity protection, as well as electrical isolation between diode and case.
Reliable connector construction
Isolated metal case
Simple to mount
