APEM 3-Axis Joystick Conical Momentary, IP67, IP69K, 12 V ac, 12 V dc, 50 mA

View all Joysticks
Bulk discount available

Subtotal (1 unit)*

PHP12,082.03

(exc. VAT)

PHP13,531.87

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 26 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per Unit
1 - 9PHP12,082.03
10 - 24PHP11,598.75
25 - 49PHP11,115.47
50 +PHP10,390.55

*price indicative

RS Stock No.:
242-0751
Mfr. Part No.:
NVH2D1C0CP2S
Manufacturer:
APEM
Find similar products by selecting one or more attributes.
Select all

Brand

APEM

Series

NV

Product Type

Joystick

Number of Axes

3

Switch Technology

Momentary

IP Rating

IP67, IP69K

Handle Type

Conical

Contact AC Voltage

12V ac

Switch Contact Current

50 mA

Contact Material

Brass

Joystick Travel

12 °

Contact DC Voltage

12V dc

Mechanical Life

1000000Cycles

Standards/Approvals

IEC 60529, IEC 68-2-14/Na, IEC 60068-2-27, IEC 60068-2-11/KA, DIN 40050-9, IEC 68-2-78, IEC 60068-2-6, IEC 60068-2-64

Maximum Operating Temperature

65°C

Minimum Operating Temperature

-40°C

COO (Country of Origin):
FR
The APEM NV 5-Way Switch-Based Joysticks offer four directional outputs plus a fifth center pushbutton option. NV 5-way joysticks provide a positive, tactile feedback in all directions for precise and secure fingertip control. The series is designed to withstand adverse conditions, such as water, frost, dust, sand, and hydrocarbons, while maintaining its tactile feedback during excessive shock and vibration. Rated at over 1 million mechanical life cycles per direction, NV 5-way joysticks are ideal for remote control applications requiring a compact and highly reliable navigational control.

4 or 5 momentary NO electrical function

50mA maximum current/voltage rating with resistive load

Electrical life at full load

1 million cycles per direction

1 million cycles for pushbutton

-40°C to +65°C operating temperature range
