Lapp ÖLFLEX® H07Z-K 90° Series Blue 1.5 mm² Hook Up Wire, 15 AWG, 100m
- RS Stock No.:
- 721-0633
- Mfr. Part No.:
- 4726021
- Manufacturer:
- Lapp
14 In Global stock for delivery NCR Plus within 10 working day(s), rest of PH within 14 working days
Price 1 Reel of 100 Metre(s)
PHP7,949.80
(exc. VAT)
PHP8,903.78
(inc. VAT)
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | PHP7,949.80 | PHP79.498 |
*price indicative
- RS Stock No.:
- 721-0633
- Mfr. Part No.:
- 4726021
- Manufacturer:
- Lapp
Low Smoke Halogen Free Single Core Cable - H07Z-K
From Lapp, this low smoke zero halogen cable is designed for use in internal wiring. The single core harmonized cable can be used to wire appliances and fittings, and is also ideal for installation in conduits and sealed trunking.
As it is low smoke zero halogen (LSZH) it is suitable for environments where the protection of people and equipment is paramount. In the event of a fire, this wire will release far less smoke and no harmful halogens when burning compared to non-LSZH wiring.
With a fine copper wire construction, the wire also features a halogen free core. The cable is also certified, meaning it is suitable for use in most European machinery.
Features and Benefits
• LSZH
• H07Z-K 90°C
• Harmonized (HAR)
• Flame retardant in accordance to IEC 60332-2-2
• Smoke density in accordance to IEC 61034
• Halogen free in accordance to IEC 60754-1
• Operating Temperature of Temperature range -15°C → +90°C
Applications
Lapp LSZH wire releases less toxic and corrosive gases into an environment when burning, which is essential for areas with low ventilation, such as aircraft and off-shore installations. It is also often used in;
• Underground Railway
• Ships
• Power Plants and Nuclear Facilities
The H05Z-K cable must be used in dry rooms, and can installed in tubes under plaster and in installed installation ducts. It is often used in;
• Control Cabinets
• Switchgear Cabinets
• Distribution Boxes
Accessories
For proper termination and management in control cabinets and conduit, this wire can be used with cable accessories and Lapp cable glands. For example, the easy-fit SKINTOP CLICK range of cable glands can accommodate various wire gauges.
• 104-004 is a grey M16 SKINTOP CLICK Cable Gland for 4.5 mm to 10 mm wire diameters
• 104-010 is a grey M20 SKINTOP CLICK Cable Gland for 7 mm to 13 mm wire diameters
• 103-994 is a grey M25 SKINTOP CLICK Cable Gland for 9 mm to 17 mm wire diameters
• 560-707 is a grey M12 SKINTOP CLICK Cable Gland for 3 mm to 7 mm wire diameters
• 560-688 is a black M32 SKINTOP CLICK Cable Gland for 11 mm to 21 mm wire diameters
As it is low smoke zero halogen (LSZH) it is suitable for environments where the protection of people and equipment is paramount. In the event of a fire, this wire will release far less smoke and no harmful halogens when burning compared to non-LSZH wiring.
With a fine copper wire construction, the wire also features a halogen free core. The cable is also
Features and Benefits
• LSZH
• H07Z-K 90°C
• Harmonized (HAR)
• Flame retardant in accordance to IEC 60332-2-2
• Smoke density in accordance to IEC 61034
• Halogen free in accordance to IEC 60754-1
• Operating Temperature of Temperature range -15°C → +90°C
Applications
Lapp LSZH wire releases less toxic and corrosive gases into an environment when burning, which is essential for areas with low ventilation, such as aircraft and off-shore installations. It is also often used in;
• Underground Railway
• Ships
• Power Plants and Nuclear Facilities
The H05Z-K cable must be used in dry rooms, and can installed in tubes under plaster and in installed installation ducts. It is often used in;
• Control Cabinets
• Switchgear Cabinets
• Distribution Boxes
Accessories
For proper termination and management in control cabinets and conduit, this wire can be used with cable accessories and Lapp cable glands. For example, the easy-fit SKINTOP CLICK range of cable glands can accommodate various wire gauges.
• 104-004 is a grey M16 SKINTOP CLICK Cable Gland for 4.5 mm to 10 mm wire diameters
• 104-010 is a grey M20 SKINTOP CLICK Cable Gland for 7 mm to 13 mm wire diameters
• 103-994 is a grey M25 SKINTOP CLICK Cable Gland for 9 mm to 17 mm wire diameters
• 560-707 is a grey M12 SKINTOP CLICK Cable Gland for 3 mm to 7 mm wire diameters
• 560-688 is a black M32 SKINTOP CLICK Cable Gland for 11 mm to 21 mm wire diameters
A flexible low smoke halogen free single core cable for internal wiring
Intended for installation within conduits and trunking, as well as internal wiring within appliances and fittings
Can be used in all areas where in an event of fire a protection of people and equipment is paramount
Flame retardant in accordance to IEC 60332-1-2
Smoke density in accordance to IEC 61034
Halogen free in accordance to IEC 60754-1
Working voltage 450/750V
Test Voltage 2500Vac
Temperature range -15°C → +90°C
Intended for installation within conduits and trunking, as well as internal wiring within appliances and fittings
Can be used in all areas where in an event of fire a protection of people and equipment is paramount
Flame retardant in accordance to IEC 60332-1-2
Smoke density in accordance to IEC 61034
Halogen free in accordance to IEC 60754-1
Working voltage 450/750V
Test Voltage 2500Vac
Temperature range -15°C → +90°C
Attribute | Value |
|---|---|
| Cross Sectional Area | 1.5 mm² |
| Sheath Colour | Blue |
| American Wire Gauge | 15 AWG |
| Cable Shape | Single Core |
| Length | 100m |
| Outer Diameter | 3.5mm |
| Voltage Rating | 750 V |
| Minimum Operating Temperature | -15°C |
| CPR Certification | Eca |
| Maximum Operating Temperature | +90°C |
| Conductor Material | Copper |
| Wire Style | 2491B |
| Series | ÖLFLEX® H07Z-K 90° |
