Schneider Electric Foot Switch Contact Block for Foot Switch

Metal housed footswitches, with or without protective guard cover. The guarded cover types are strongly recommended in high risk areas where accidental starting of the machine, either by human action or falling objects can occur. Footswitches featuring 2 step contact operation are ideal for applications involving 2 speed machines. The first step (6mm travel) operates one set of NC + NO contacts before the second step operates the other NC + NO contacts during full actuator travel (12mm). The trigger action types enable locking of the pedal in rest position, positive action is required before the pedal can be depressed.

Available with or without trigger mechanism in 1 or 2 step configurations
Large surface area of pedal assures stability of foot and operator comfort
High and wide protective cover accommodates both large size and safety boots
Can be fixed to the floor or on a support for improved stability
Blue IP66 metal housing

CSA

To keep your pedal-powered switches trucking along, trust this foot switch contact block from Schneider Electric. It's designed to make or break an electrical circuit when installed with a compatible switching device. This lets you stop or start connected machinery, including safety devices, in a jiffy. The block measures a standard 25 (H) x 30 (W) x 40mm (L) and only weighs 20g, so it fits neatly into your setup and keeps it free from excess load.

• Maximum operating humidity of 95% RH for use in areas prone to high moisture levels
• Screw connection allows for a speedy setup using a slotted or Phillips screwdriver
• Broad operating temperature range of -20°C to +60°C, so it holds its own in harsh environments

• Industrial automation and control
• Assembly lines
• Machine tooling
• Pick and pack conveyors

Yes. This component is compatible with two-step foot switches, so you can use it with equipment that runs at two operating speeds.

Industrial Duty Footswitches

A range of robust footswitches suited for industrial environments issuing start and normal stop instructions to many types of machines. They allow the operator greater freedom of movement.
