Omron G2RV-ST Series Electromechanical Interface Relay, DIN Rail, 230V ac Coil, SPDT, 6.8mA
- RS Stock No.:
- 271-1838
- Mfr. Part No.:
- G2RV-ST500 230VAC
- Manufacturer:
- Omron
Subtotal (1 unit)*
PHP1,665.75
(exc. VAT)
PHP1,865.64
(inc. VAT)
FREE delivery for orders over ₱3,000.00
In Stock
- 5 unit(s) ready to ship from another location
- Plus 80 unit(s) shipping from May 26, 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 + | PHP1,665.75 |
*price indicative
- RS Stock No.:
- 271-1838
- Mfr. Part No.:
- G2RV-ST500 230VAC
- Manufacturer:
- Omron
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Coil Resistance | 100mΩ | |
| Product Type | Electromechanical Interface Relay | |
| Coil Voltage | 230V ac | |
| Contact Configuration | SPDT | |
| Mount Type | DIN Rail | |
| Series | G2RV-ST | |
| Terminal Type | Push-in | |
| Coil Current | 6.8mA | |
| Switching AC Voltage | 440V ac | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 55°C | |
| Contact Material | Silver Alloy | |
| Width | 6.2mm | |
| Standards/Approvals | CE, cULus | |
| Length | 88mm | |
| Height | 90mm | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Coil Resistance 100mΩ | ||
Product Type Electromechanical Interface Relay | ||
Coil Voltage 230V ac | ||
Contact Configuration SPDT | ||
Mount Type DIN Rail | ||
Series G2RV-ST | ||
Terminal Type Push-in | ||
Coil Current 6.8mA | ||
Switching AC Voltage 440V ac | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 55°C | ||
Contact Material Silver Alloy | ||
Width 6.2mm | ||
Standards/Approvals CE, cULus | ||
Length 88mm | ||
Height 90mm | ||
- COO (Country of Origin):
- MY
Omron G2RV-ST Series Electromechanical Interface Relay, 100 MΩ Control Resistance, 6.8 mA Input Current - G2RV-ST500 AC230
This Omron product is a DIN rail-mounted electromechanical interface relay. It features a 230V AC coil, SPDT configuration, and a load current of 6A.
Features & Benefits
• Easy installation and organization of multiple relays on a standard DIN rail
• SPDT configuration provides flexibility to switch between two different circuits
• Handles higher current loads of 6A without overheating
Applications
• Reliable control of motor-driven equipment in industrial automation and manufacturing processes
• Manages lighting circuits in buildings, warehouses, or outdoor areas
• Suitable for heating, ventilation, and air conditioning (HVAC) systems
What is the coil voltage of this relay?
The coil voltage is 230V AC.
Can I use this relay for motor control applications?
Yes, it’s suitable for motor control tasks such as switching pumps, fans, or conveyor belts.
What load current can this relay handle?
It can handle a load current of 6A.
