WAGO 859 Series Interface Relay, DIN Rail Mount, 24V ac/dc Coil, SPDT, 5A Load

RS Stock No.:: 180-3050
Mfr. Part No.:: 859-354
Manufacturer:: WAGO

WAGO 859 Series Interface Relay, DIN Rail Mount, 24V ac/dc Coil, SPDT, 5A Load

Subtotal (1 unit)*

PHP2,342.35

(exc. VAT)

PHP2,623.43

(inc. VAT)

FREE delivery for orders over ₱3,000.00

In Stock

57 unit(s) ready to ship from another location

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per Unit
1 +	PHP2,342.35

*price indicative

RS Stock No.:: 180-3050
Mfr. Part No.:: 859-354
Manufacturer:: WAGO

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	WAGO
	Coil Voltage	24V ac/dc
	Contact Configuration	SPDT
	Mounting Type	DIN Rail
	Series	859
	Load Current Rating	5A
	Load Voltage Rating	250V ac
	Maximum Input Voltage	24V ac/dc
	Terminal Type	Cage Clamp
	Switching Voltage	250V ac
	Depth	91mm
	Height	56mm
	Length	6mm
	Contact Material	Silver Alloy
	Input Current	8mA
	Special Features	LED Indication
	Standards Met	DNV GL TAA00001D1, EN 61010-2-201, EN 61373, EN 61810-1, GL, NK TA17255M, PRS TE/1989/880590/13, UL, UL E175199 Sec.6
	Relay Switching Classification	Miniature Switching Relay
	Input Voltage Range	(Maximum) 24V ac/dc
	Maximum Operating Temperature	+50°C
	Minimum Operating Temperature	-25°C
	Dimensions	6 x 56 x 91mm
	Operating Temperature Range	-25 → +50°C
	Life	5 x 10^6 (Mechanical) cycles, 50 x 10^3 (Electrical) cycles

	Select all
	Brand WAGO
	Coil Voltage 24V ac/dc
	Contact Configuration SPDT
	Mounting Type DIN Rail
	Series 859
	Load Current Rating 5A
	Load Voltage Rating 250V ac
	Maximum Input Voltage 24V ac/dc
	Terminal Type Cage Clamp
	Switching Voltage 250V ac
	Depth 91mm
	Height 56mm
	Length 6mm
	Contact Material Silver Alloy
	Input Current 8mA
	Special Features LED Indication
	Standards Met DNV GL TAA00001D1, EN 61010-2-201, EN 61373, EN 61810-1, GL, NK TA17255M, PRS TE/1989/880590/13, UL, UL E175199 Sec.6
	Relay Switching Classification Miniature Switching Relay
	Input Voltage Range (Maximum) 24V ac/dc
	Maximum Operating Temperature +50°C
	Minimum Operating Temperature -25°C
	Dimensions 6 x 56 x 91mm
	Operating Temperature Range -25 → +50°C
	Life 5 x 10^6 (Mechanical) cycles, 50 x 10^3 (Electrical) cycles

Datasheet

COO (Country of Origin):: DE

Relay module, Nominal input voltage: 24 V AC/DC, 1 changeover contact, Red status indicator, Module width: 6 mm
