Vishay, SIC467ED-T1-GE3 DC-DC Converter, 1-Channel 6A Adjustable 27-Pin, PowerPAK MLP55
- RS Stock No.:
- 188-4861
- Mfr. Part No.:
- SIC467ED-T1-GE3
- Manufacturer:
- Vishay
View all Buck Converters
Temporarily out of stock - back order for despatch 08/09/2023, delivery within 10 working days from desptach date
Price Each (On a Reel of 3000)
PHP161.553
(exc. VAT)
PHP180.939
(inc. VAT)
| units | Per Unit | Per Reel* |
| 3000 - 3000 | PHP161.553 | PHP484,659.00 |
| 6000 + | PHP156.706 | PHP470,118.00 |
| *price indicative | ||
- RS Stock No.:
- 188-4861
- Mfr. Part No.:
- SIC467ED-T1-GE3
- Manufacturer:
- Vishay
Technical data sheets
Legislation and Compliance
Product Details
Single supply operation from 4.5 V to 60 V input voltage
Adjustable output voltage down to 0.8 V
Scalable solution 2 A (SiC469), 4 A (SiC468), 6 A (SiC467), 10 A (SiC466)
Output voltage tracking and sequencing with pre-bias start up
± 1 % output voltage accuracy at -40 °C to +125 °C
Internal compensation
Highly efficient
98 % peak efficiency
4 μA supply current at shutdown
100 μA operating current not switching
Highly configurable
Adjustable switching frequency from 100 kHz to 2 MHz
Adjustable soft start and selectable preset 100 %, 75 %, and 50 % current limit
2 modes of operation, forced continuous conduction, power save
Robust and reliable
Output over voltage protection
Output under voltage / short circuit protection with auto retry
Power good flag and over temperature protection
Supported by Vishay PowerCAD online design simulation
Design support tools
PowerCAD online design simulation
External component calculator
Schematic, design, BOM, and gerber files
Adjustable output voltage down to 0.8 V
Scalable solution 2 A (SiC469), 4 A (SiC468), 6 A (SiC467), 10 A (SiC466)
Output voltage tracking and sequencing with pre-bias start up
± 1 % output voltage accuracy at -40 °C to +125 °C
Internal compensation
Highly efficient
98 % peak efficiency
4 μA supply current at shutdown
100 μA operating current not switching
Highly configurable
Adjustable switching frequency from 100 kHz to 2 MHz
Adjustable soft start and selectable preset 100 %, 75 %, and 50 % current limit
2 modes of operation, forced continuous conduction, power save
Robust and reliable
Output over voltage protection
Output under voltage / short circuit protection with auto retry
Power good flag and over temperature protection
Supported by Vishay PowerCAD online design simulation
Design support tools
PowerCAD online design simulation
External component calculator
Schematic, design, BOM, and gerber files
Specifications
| Attribute | Value |
| Maximum Output Current | 6A |
| Regulator Function | Synchronous Buck Regulator |
| Minimum Output Voltage | 0.8 V |
| Minimum Input Voltage | 4.5 V |
| Maximum Input Voltage | 60 V |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Pin Count | 27 |
| Maximum Switching Frequency | 2 MHz |
| Package Type | PowerPAK MLP55 |
| Switching Regulator | Yes |
| Minimum Operating Temperature | -40 °C |
| Efficiency | 98 (Peak)% |
| Length | 5.1mm |
| Dimensions | 5.1 x 5.1 x 0.75mm |
| Width | 5.1mm |
| Maximum Operating Temperature | +150 °C |
| Height | 0.75mm |
