Pneumatic Cylinder Sensors

Created and designed to produce linear motion, our pneumatic cylinder sensors are the ideal solution for important industrial processing applications such as clamping and positioning. These devices are also designed to detect the linear position of a piston, predominantly used in applications where position feedback is required.

Magnetic sensors, which are formally known as reed sensors are one of the most common proximity sensors found being used in conjunction with pneumatic cylinders, they detect the magnetic field of a magnet that is integrated within the piston of the cylinder. The sensor is usually mounted on the exterior of the piston body, switching on or off when it is either near the magnet or not.

Many of our pneumatic cylinder sensors feature an LED indicator, choices that are ATEX approved and different sizes and ports to suit your specific application.

Types of Pneumatic Cylinder & Actuators

Browse our range and you will find that we have a huge variety of different types.

  • Some of our sensors are magneto resistive
  • Solid-state
  • Transmitters
  • Magnetic hall
  • Featuring a floating contact
  • Electronic PNP

RS Components offers you the world's most reliable and market-leading brands, allowing you to choose your pneumatic cylinder sensors with ease and trust. Choose from Festo, SMC and of course our trusted own brand RS PRO.


...
Read more Read less

Filters

Viewing 1 - 20 of 339 products
Results per page
Description Price Manufacturer Series Compatible With Type LED Indicator IP Rating Supply Voltage Operation Minimum Operating Pressure Minimum Operating Temperature Maximum Operating Temperature Maximum Operating Pressure Hazardous Area Certification Outlet Port Outlet Port - Tube Size
RS Stock No. 826-2073
Mfr. Part No.D-A93
BrandSMC
PHP1,498.41
Each
units
D-A9 Size 05, Size 10 to 200 MSQ Series Rotary Actuator, Size 10 to 40 CDRQ2 Series Rotary Actuator, Size 10 to 40 CDRQ2X Series Rotary Actuator, Size 10 to 50 MSQX Series Rotary Actuator, Size 10 to 50 MSZ Series Rotary Actuator, Size 32 to 63 MHT2 Series Rotary Actuator, 1 CRJ Series Rotary Actuator Reed Yes IP67 24 V dc, 100V ac - - -10°C +60°C - - - -
RS Stock No. 826-2114
Mfr. Part No.D-A54
BrandSMC
PHP1,866.43
Each
units
D-A5 NCA1 Series Cylinder, Size 10, 15 CDRB Series Rotary Actuator Reed Yes IP67 200V ac - - -10°C +60°C - - - -
RS Stock No. 121-5825
Mfr. Part No.SME-8M-DS-24V-K-2,5-OE
BrandFesto
PHP1,569.64
Each
units
SME T-Slot Reed Yes IP65, IP68 24V dc NO - -40°C +70°C - - - -
RS Stock No. 796-7329
Mfr. Part No.D-A73H
BrandSMC
PHP1,437.49
Each
units
D-A7 PLC Auto Switch Yes IP67 - - - -10°C +60°C - - - -
RS Stock No. 815-7779
Mfr. Part No.P494A0022100A00
PHP3,467.96
Each
units
494 431 Series, 435 → 438 Series, 441 → 447 Series, 449 → 454 Series Magneto Resistive PNP Yes IP67, IP69K 10 to 30V dc NO - -25°C +85°C - - - -
RS Stock No. 815-7788
Mfr. Part No.P494A0022500A00
PHP3,564.43
Each
units
494 431 Series, 435 → 438 Series, 441 → 447 Series, 449 → 454 Series Magneto Resistive PNP Yes IP67, IP69K 10 to 30V dc NO - -25°C +85°C - - - -
RS Stock No. 815-7781
Mfr. Part No.P494A0022600A00
PHP3,072.30
Each
units
494 431 Series, 435 → 438 Series, 441 → 447 Series, 449 → 454 Series Magneto Resistive PNP Yes IP67, IP69K 10 to 30V dc NO - -25°C +85°C - - - -
RS Stock No. 192-9514
Mfr. Part No.M/40
PHP6,907.12
Each
units
M/4 A44000 Reed Yes IP66 10 → 170 V dc, 10 → 240V ac NO - 0°C +70°C - - - -
RS Stock No. 912-0976
Mfr. Part No.D-A93SAPC
BrandSMC
PHP2,519.40
Each
units
D-A9 - Reed Yes - - - - -10°C +60°C - - - -
RS Stock No. 111-3709
Mfr. Part No.RZT7-03ZRS-KP0
BrandSick
PHP1,381.47
Each
units
- - - - IP65, IP67 - - - - - - - - -
RS Stock No. 125-9954
Mfr. Part No.SME-8M-DS-24V-K-7,5-OE
BrandFesto
PHP1,960.79
Each
units
SME T-Slot Reed - IP65, IP68 5 to 30 V ac/dc, 24V dc NO - -40°C +70°C - - Wire -
RS Stock No. 121-5837
Mfr. Part No.SMT-8M-A-PS-24V-E-2,5-OE
BrandFesto
PHP2,223.73
Each
units
SMT-8 T-Slot Magneto Resistive Yes IP65, IP68, IP69K 24V dc NO - -40°C +85°C - - - -
RS Stock No. 849-7092
Mfr. Part No.D-97
BrandSMC
PHP1,422.35
Each
units
D-97 - Reed Yes IP67 - - - -10°C +60°C - - - -
RS Stock No. 826-2120
Mfr. Part No.D-A90
BrandSMC
PHP1,498.41
Each
units
D-A9 Size 05, Size 10 to 200 MSQ Series Rotary Actuator, Size 10 to 40 CDRQ2 Series Rotary Actuator, Size 10 to 40 CDRQ2X Series Rotary Actuator, Size 10 to 50 MSQX Series Rotary Actuator, Size 10 to 50 MSZ Series Rotary Actuator, Size 32 to 63 MHT2 Series Rotary Actuator, 1 CRJ Series Rotary Actuator Reed No IP67 100V ac/dc - - -10°C +60°C - - - -
RS Stock No. 121-5823
Mfr. Part No.SME-8M-DO-24V-K-7,5-OE
BrandFesto
PHP2,131.63
Each
units
SME T-Slot Reed Yes IP65, IP68 24V dc NC - -40°C +70°C - - - -
RS Stock No. 849-7332
Mfr. Part No.D-H7A2
BrandSMC
PHP2,753.00
Each
units
D-H7A - Solid State Yes IP67 4.5 to 28V dc - - -10°C +60°C - - - -
RS Stock No. 179-5285
Mfr. Part No.R412022872
PHP1,687.30
Each
units
ST6 CCI, CVI, GPC, KPZ, PRA, PRE, SSI Reed Yes IP65, IP67 10 to 30V dc NO - -30°C +80°C - - - -
New
RS Stock No. 212-8731
Mfr. Part No.MZT8-03VPS-KU0
BrandSick
PHP2,555.71
Each
units
MZT8 T-Slot Magnetic Cylinder Sensor Yes - 10 → 30V dc - - -30°C +80°C - - Wire -
New
RS Stock No. 218-0739
Mfr. Part No.QM/34/5
PHP2,140.38
Each
units
QM/34 M/1001, M/900, RA/8000 Reed Yes IP66 - - - - - - - - -
RS Stock No. 175-2132
Mfr. Part No.SFAB-10U-HQ6-2SA-M12
BrandFesto
PHP21,507.19
Each
units
- - - - - 0 → 10V - - 0°C +50°C - ATEX - -
