W Robinson And Sons 230 V Direct Coupling Submersible Submersible Water Pump, 160L/min
- RS Stock No.:
- 214-5206
- Mfr. Part No.:
- 555039
- Manufacturer:
- W Robinson And Sons
18 In Global stock for delivery NCR Plus within 10 working day(s), rest of PH within 14 working days
Added
Price Each
PHP35,687.47
(exc. VAT)
PHP39,969.97
(inc. VAT)
| Units | Per Unit |
| 1 - 4 | PHP35,687.47 |
| 5 + | PHP34,795.29 |
- RS Stock No.:
- 214-5206
- Mfr. Part No.:
- 555039
- Manufacturer:
- W Robinson And Sons
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- IT
Product Details
W Robinson And Sons Submersible Water Pump
The W Robinson And Sons submersible wastewater pump is the latest device manufactured from 304 stainless steel. This centrifugal pump is used in conditions where contamination or rust is unacceptable. It is an effective product with a maximum flow rate of 160L/minute.
Inclusion:
10m H07 RNF cable conforming to current regulations
.
Inclusion:
10m H07 RNF cable conforming to current regulations
.
Features and Benefits
The supply voltage is between 1V to 240V
Maximum fluid temperature is 50°C
Thermal overload motor, double seal, lubricated in oil sump and interchangeable ceramic brush on rotating shaft
Insulation class F
Lubricated in oil sump and protected by V-ring sand-guard
Self-sealing vortex system impeller in cast stainless steel
Free passage of 20mm solids
Maximum fluid temperature is 50°C
Thermal overload motor, double seal, lubricated in oil sump and interchangeable ceramic brush on rotating shaft
Insulation class F
Lubricated in oil sump and protected by V-ring sand-guard
Self-sealing vortex system impeller in cast stainless steel
Free passage of 20mm solids
Applications
Used to drain seepage
To pump up clear and waste rainwater from gratings or wells
To pump waste and clear water of domestic, civil, and industrial use
For channel irrigation system and water transferring from streams
Basins and lakes
Drainage of rooms, tanks and swimming pools of clear, waste, muddy, and slimy water
Used also for industrial application such as spraying booths, transferring liquids, washing, etc
To pump up clear and waste rainwater from gratings or wells
To pump waste and clear water of domestic, civil, and industrial use
For channel irrigation system and water transferring from streams
Basins and lakes
Drainage of rooms, tanks and swimming pools of clear, waste, muddy, and slimy water
Used also for industrial application such as spraying booths, transferring liquids, washing, etc
Specifications
Attribute | Value |
|---|---|
| Maximum Flow Rate | 160L/min |
| Supply Voltage | 1 → 240 V |
| Maximum Head | 7m |
| Body Material | Stainless Steel |
| Coupling Type | Direct |
| Maximum Fluid Temperature | +50°C |
| Output Connection Size | 1-1/4in |
| Pump Type | Submersible |
| IP Rating | IP68 |
