- RS Stock No.:
- 475-120
- Mfr. Part No.:
- 53112911
- Manufacturer:
- Lapp
260 In Global stock for delivery NCR Plus within 10 working day(s), rest of PH within 14 working days
Added
Price Each (In a Pack of 10)
PHP265.482
(exc. VAT)
PHP297.34
(inc. VAT)
Units | Per Unit | Per Pack* |
10 - 40 | PHP265.482 | PHP2,654.82 |
50 - 90 | PHP257.517 | PHP2,575.17 |
100 + | PHP249.793 | PHP2,497.93 |
*price indicative |
- RS Stock No.:
- 475-120
- Mfr. Part No.:
- 53112911
- Manufacturer:
- Lapp
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
Lapp IP68 Metric Skintop Click BS Strain Relief Cable Glands
With a tough polyamide construction, the Skintop Click series has excellent environmental protection. They are sealed to IP68, which means it is well protected against dust ingress and moisture, even to the point of shallow immersion. This makes them ideal for harsh environments, or even for outdoor use.
They install quickly and simply with a click and turn action with no thread required. They fit into pre-drilled holes in panels, junction boxes and equipment with ease, dramatically cutting assembly times.
The cable gland is also resistant to UV rays, and their protection from vibration makes them suitable for use with heavy machinery.
The Skintop Click BS cable glands have an integrated strain relief that offers a high degree of bend protection, which defends the cable connection from wear and tear. This makes them ideal for cable attachment to hand held equipment and flexing machine parts.
Features and Benefits
IP68 environmental resistance
Click fit easy mounting
Integrated strain relief
Dynamic operating temperature range of -20°C to +100
Resistant to UV rays
Vibration protection
Applications
Skintop Click cable glands offer a fast and convenient cable connection, and are ideal where flexibility is needed, such as:
Robotics
Moving Machine Parts
Apparatus Construction
Environment
With a tough polyamide construction, the Skintop Click series has excellent environmental protection. They are sealed to IP68, which means it is well protected against dust ingress, and moisture, even to the point of shallow immersion. This makes them ideal for harsh environments, or even outdoor use.
The cable gland is also resistant to UV rays and offers protection from vibration.
Accessories
Accessories are available for the Skintop Click Range of Cable Glands:
Removal Tool, size M20 0475069
Removal Tool, size M25 0475063
Blanking Plug, size M16 0475053
Blanking Plug, size M20 0475081
Blanking Plug, size M25 0475085
They install quickly and simply with a click and turn action with no thread required. They fit into pre-drilled holes in panels, junction boxes and equipment with ease, dramatically cutting assembly times.
The cable gland is also resistant to UV rays, and their protection from vibration makes them suitable for use with heavy machinery.
The Skintop Click BS cable glands have an integrated strain relief that offers a high degree of bend protection, which defends the cable connection from wear and tear. This makes them ideal for cable attachment to hand held equipment and flexing machine parts.
Features and Benefits
IP68 environmental resistance
Click fit easy mounting
Integrated strain relief
Dynamic operating temperature range of -20°C to +100
Resistant to UV rays
Vibration protection
Applications
Skintop Click cable glands offer a fast and convenient cable connection, and are ideal where flexibility is needed, such as:
Robotics
Moving Machine Parts
Apparatus Construction
Environment
With a tough polyamide construction, the Skintop Click series has excellent environmental protection. They are sealed to IP68, which means it is well protected against dust ingress, and moisture, even to the point of shallow immersion. This makes them ideal for harsh environments, or even outdoor use.
The cable gland is also resistant to UV rays and offers protection from vibration.
Accessories
Accessories are available for the Skintop Click Range of Cable Glands:
Removal Tool, size M20 0475069
Removal Tool, size M25 0475063
Blanking Plug, size M16 0475053
Blanking Plug, size M20 0475081
Blanking Plug, size M25 0475085
Features and Benefits
Available in black or grey
Thread size of M12 to M32
Operating temperature of -20°C to +100°C
Components
Body: polyamide based plastic (UL 94- V2)
Bending protection: polyamide based plastic (UL 94- V2)
Seal insert: elastomer
Pressure nut: polyamide based plastic, fibre-glass reinforced (UL 94- V2)
Flat seating ring: elastomer/thermoplastic
Typical Applications
The Skintop Click BS is designed for use within particular functional safety in hand held equipment, flexing machine parts, apparatus engineering, light and sound applications and robotics industry.
Approvals
VDE
Standards
EN60529
Specifications
Attribute | Value |
---|---|
Thread Size | M20 |
Maximum Cable Diameter | 13mm |
Minimum Cable Diameter | 7mm |
Material | Polyamide |
Colour | Black |
Series | SKINTOP |
IP Rating | IP68 |
Locknut Included | No |
Fire Behaviour | Heat Resistant |
Minimum Operating Temperature | -20°C |
Maximum Operating Temperature | +100°C |
Operating Temperature Range | -20 → +100 °C |
Reference | SKINTOP CLICK BS |
