EA Elektro-Automatik EA-PSI 9000 T Series Digital Bench Power Supply, 0 → 200V, 25A, 1-Output, 1.5kW
- RS Stock No.:
- 138-6113
- Mfr. Part No.:
- EA-PSI 9200-25 T
- Manufacturer:
- EA Elektro-Automatik
5 In Global stock for delivery NCR Plus within 10 working day(s), rest of PH within 14 working days
Added
Price Each
PHP165,941.11
(exc. VAT)
PHP185,854.04
(inc. VAT)
Units | Per Unit |
1 + | PHP165,941.11 |
- RS Stock No.:
- 138-6113
- Mfr. Part No.:
- EA-PSI 9200-25 T
- Manufacturer:
- EA Elektro-Automatik
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
EA PSI 9000 T Series
The microprocessor controlled laboratory power supplies of series EA-PSI 9000 T offer a user-friendly, interactive handling concept, along with a ex-tensive set of standard features, which can facilitate operating them. Configuration of output parameters, supervision features and other settings is smart and comfortable.
The implemented supervision features for all output parameters can help to reduce test equipment and make it almost unnecessary to install external supervision hardware and software.
The implemented supervision features for all output parameters can help to reduce test equipment and make it almost unnecessary to install external supervision hardware and software.
Features and Benefits
Wide input voltage range 90...264 V with active PFC
High efficiency up to 92%
Output power ratings: 0...320 W up to 0...1500 W
Output voltages: 0...40 V up to 0...500 V
Output currents: 0...4 A up to 0...60 A
Flexible, power regulated output stage
Supervision (OVP, OCP, OPP)
Over-temperature protection (OT)
Intuitive touch panel with display for values, status and notifications
USB port as standard, Ethernet & analogue optional (all interfaces galvanically isolated)
Integrated function generator
Internal resistance simulation and regulation
40 V models compliant to SELV (EN 60950)
SCPI command language supported
LabView VIs
Control software for Windows
High efficiency up to 92%
Output power ratings: 0...320 W up to 0...1500 W
Output voltages: 0...40 V up to 0...500 V
Output currents: 0...4 A up to 0...60 A
Flexible, power regulated output stage
Supervision (OVP, OCP, OPP)
Over-temperature protection (OT)
Intuitive touch panel with display for values, status and notifications
USB port as standard, Ethernet & analogue optional (all interfaces galvanically isolated)
Integrated function generator
Internal resistance simulation and regulation
40 V models compliant to SELV (EN 60950)
SCPI command language supported
LabView VIs
Control software for Windows
Elektro-Automatik
Specifications
Attribute | Value |
---|---|
Series | EA-PSI 9000 T |
Model Number | EA-PSI 9200-25 T |
Number of Outputs | 1 |
Output Voltage | 0 → 200V |
Supply Voltage | 90 → 264V ac |
Output Current | 25A |
Power Rating | 1.5kW |
Number of Displays | 1 |
Bench Power Supply Type | Programmable DC Power Supply |
Type | Digital |
Digital/Analogue | Digital |
Input Connector | IEC Type Plug |
Maximum Temperature | +50°C |
Minimum Temperature | 0°C |
