SKF 6215-2RS1/C3 Single Row Deep Groove Ball Bearing- Both Sides Sealed 75mm I.D, 130mm O.D
- RS Stock No.:
- 505-968
- Mfr. Part No.:
- 6215-2RS1/C3
- Manufacturer:
- SKF
5 In Global stock for delivery NCR Plus within 10 working day(s), rest of PH within 14 working days
Added
Price Each
PHP7,239.24
(exc. VAT)
PHP8,107.95
(inc. VAT)
| Units | Per Unit |
| 1 - 5 | PHP7,239.24 |
| 6 - 24 | PHP6,949.67 |
| 25 + | PHP6,660.10 |
- RS Stock No.:
- 505-968
- Mfr. Part No.:
- 6215-2RS1/C3
- Manufacturer:
- SKF
Technical data sheets
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- FR
Product Details
Deep Groove Metric Ball Bearings - Sealed
Sealed (2RS1) bearings are fitted with two synthetic rubber seals to prevent leakage of lubricant and entry of dust, water and other harmful material.
Features and Benefits
• The seals are made from an oil and wear-resistant synthetic rubber with a steel reinforcement
• Operating temperature from -40°C to +120°C
• Accepts radial and axial loads
• Both standard and C3 clearance available
• Versatile
• Operating temperature from -40°C to +120°C
• Accepts radial and axial loads
• Both standard and C3 clearance available
• Versatile
Application Information
Deep groove ball bearings are suitable for high speeds and are robust in operation.
Specifications
Attribute | Value |
|---|---|
| Inside Diameter | 75mm |
| Outside Diameter | 130mm |
| Race Width | 25mm |
| Ball Bearing Type | Single Row Deep Groove Ball Bearing |
| Sealing Arrangement | Both Sides Sealed |
| Bearing Clearance | C3 |
| Material | Steel |
| Ball Material | Steel |
| Cage Material | Sheet Metal |
| Number of Rows | 1 |
| Static Load Rating | 49kN |
| Dynamic Load Rating | 68.9kN |
| Bore Type | Parallel |
| Bearing Series | 2 Light |
| Race Type | Plain |
| Partial Bearing Code | 6215 |
| Model Number p | 62152RS1C3 |
